J Med Cases
Journal of Medical Cases, ISSN 1923-4155 print, 1923-4163 online, Open Access
Article copyright, the authors; Journal compilation copyright, J Med Cases and Elmer Press Inc
Journal website http://www.journalmc.org

Case Report

Volume 3, Number 1, February 2012, pages 15-19


Primary Thyroid Lymphoma as A Manifestation of Rapidly Growing Thyroid Causing Progressive Respiratory Distress

Chisho Hoshinoa, b, Akane Yamabea, Yoshiyuki Sekikawaa, Kana Ishiharaa, Hiroshi Ikedaa, Masashi Naritaa, Minoru Inouea

aOhta-Nishinouchi Hospital, General Internal Medicine, 2-5-20 Nishinouchi, Koriyama City, Fukushima-ken, Japan
bCorresponding author: Chisho Hoshino

Manuscript accepted for publication October 5, 2011
Short title: Rapidly Growing Thyroid
doi: https://doi.org/10.4021/jmc387w

Abstract▴Top

The author present a 73-year-old man with rapidly glowing neck mass. He had a 6-year history of hypothyroidism-associated with Hashimoto thyroiditis and maintained L-thyroxine replacement. He had noticed progressive dyspnea with rapid enlargement of the thyroid grand over a month. An incisional biopsy of the thyroid grand for combined pathology and immunohistochemistry revealed diffuse large B cell non-Hodgkin’s lymphoma with germinal center B-cell subtype. Primary thyroid lymphoma requires prompt diagnosis because of its ability to cause progressive compression symptoms. An incisional biopsy of the thyroid grand is required for combined pathology and immunohistochemistry. Combination chemotherapy can dramatically shrink the tumor and briefly resolve the compression symptoms.

Keywords: Primary thyroid lymphoma; Hashimoto thyroiditis; A diffuse large B cell non-Hodgkin’s lymphoma; Respiratory distress; Immunohistochemistry; Combination chemotherapy

Introduction▴Top

Malignant thyroid tumors are predominantly follicular epithelial-derived, which are divided into three categories such as papillary cancer, follicular cancer, and anaplastic cancer [1-2]. non-Hodgkin’s lymphoma (NHL) most frequently arise from lymph nodes, while 10 - 30% of cases originate from extranodal sites [3] and the thyroid grand can be an important primary source of NHL, accounting for 1 - 5% of all thyroid malignancies and 1- 2.5% of all lymphomas [4]. We report a diffuse large B cell NHL (DLBCL) of the thyroid grand case, presenting as rapidly growing thyroid with progressive compression symptoms. We hope this case report will aid clinicians in the management for such a patient.

Case report▴Top

A 73-year-old man presented to our hospital complaining of rapidly growing mass in the anterior neck and progressive dyspnea of one month duration. He had no systemic symptoms, including fever, night sweats and weight loss. He had a 6-year history of hypothyroidism-associated with Hashimoto thyroiditis (HT) and maintained L-thyroxine replacement. On physical examination, a large mass was evident in the anterior neck (Fig.1). On palpation, it was an elastic hard, immobile, and nontender mass and the exact border was ill-defined. No superficial lymph node was palpable. The respiratory sound slightly decreased with prolonged expiration bilaterally. On the laboratory, a leucocyte count of 6.1 × 104/µL, hemoglobin 15.2 g/dL, platelet count 26.4 × 104/µL, lactate dehydrogenase 289 IU/L (110 - 220), soluble IL-2 receptor 2040 U/mL (145 - 519). The thyroid function was as followed: thyroid-stimulating hormone 11.0 mIU/L (0.46 - 3.7), free T3 2.15 pg/mL (1.45 - 3.48), free T4 1.51 ng/mL (0.71 - 1.85). CT scan with enhancement revealed a large cervical mass arising from thyroid which completely encircled the narrowed trachea (Fig. 2A, B). He was immediately referred to the department of endocrine surgery and under general anesthesia with endotracheal intubation, an incisional biopsy was performed for combined pathology and immunohistochemistry, that led to the diagnosis of DLBCL, with a positive immunostaining for CD10, CD20, bcl-6, but negative for MUM-1. The initial staging work-up including CT of the chest and abdomen and a bone marrow examination classified the patient as stage IIE based on the Ann Arbor staging classification [5] A combined chemotherapy including cyclophosphamide, doxorubicin, vincristine and prednisone plus rituximab (R-CHOP) was initiated, which dramatically shrunk the tumor (Fig. 3) and completely resolved the compression symptoms within a few days. After three courses of R-CHOP regimen followed by involved-field radiation therapy (IFRT), the patient is doing well with no recurrence.

Figure 1.
Click for large image
Figure 1. A large mass was evident in the anterior neck.

Figure 2.
Click for large image
Figure 2. CT scan of the neck with enhancement revealed a large cervical mass arising from thyroid which completely encircled the narrowed trachea (A: coronal section; B: transverse section).

Figure 3.
Click for large image
Figure 3. CT scan of the neck 3 weeks after the initiation of combination chemotherapy revealed the mass dramatically decreased in size.
Discussion▴Top

The association between chronic inflammatory diseases and lymphoid malignancy

Certain chronic diseases are associated with an increased risk of lymphoproliferative malignancy. Sjogren’s syndrome (SS) has known for an established predisposing factor of the development of lymphoid malignancy. According to retrospective cohort studies, 9% of patients with primary SS developed malignant lymphoma [6] and about 40 times higher than that of the general population [7]. In rheumatologic diseases, rheumatoid arthritis or systemic lupus erythematosus, especially in patients with aggressive disease, is also at increased risk of developing lymphoid malignancy [8]. In addition to rheumatologic diseases, pyothorax-associated lymphoma can develop in patients with chronic pyothorax due to lung tuberculosis or tuberculous pleuritis [9] andhelicobacter pylori infection is implicated in the pathogenesis of mucosa-associated lymphoid tissue (MALT) gastric lymphoma [10]. Characteristically, lymphomas associated with these chronic inflammatory conditions are predominantly B-cell origin.

Epidemiology of primary thyroid lymphoma

Primary thyroid lymphoma (PTL) is a heterogeneous disease, but the almost all cases of PTL are NHL with B-cell origin [4]. DLBCL and extranodal marginal zone B cell lymphoma of MALT lymphoma and coexisting both diseases are the common histologic subtypes [4, 11]. Other less common histologic subtypes include follicular lymphoma [4, 11], Hodgkin lymphoma [4, 11], small lymphocytic lymphoma [11], T-cell lymphoma [11]. There is a 4 to 1 female predominance [11] and the median age at diagnosis is around 60 year-old [4, 11].

The possible pathogenetic mechanism of developing PTL

The normal thyroid gland originally has no native lymphoid tissue. Thus, PTL is considered to arise from intrathyroid lymphoid tissue acquired during the course of chronic inflammation or an autoimmune process [11]. Pre-existing HT is known for a significant predisposing factor for PTL with an estimated relative risk of 67 [12]. Up to one-half of PTL patients have a clinical history HT, and an even more patients had pathologically diagnosed with HT [11]. PTL usually develops after a long period of HT evolution as long as 20 - 30 years [13]. It has been postulated that in HT, lymphomatous change susceptible to neoplastic transformation may be due to chronic antigenic stimulation and proliferation of lymphoid tissue [14]. Recent report supports this theory by showing sequence similarity in immunoglobulin heavy chain gene rearrangement between the clonal bands of HT and that of subsequently developed PTL [15]. In addition, aberrant somatic hypermutation, previously attributed to the development of multiple proto-oncogenesis in other types of DLBCL, may constitute a pathogenetic mechanism of developing PTL by representing an early step in the process of B-cell clonal transformation in patients with HT [16].

Diagnostic procedure of PTL

PTL presents with rapidly growing mass, which can be lethal due to progressive symptoms of tracheal, laryngeal or esophageal compression [17]. Thus, early diagnosis is essential to save the patients. Fine needle aspiration (FNA) is a valuable diagnostic tool for evaluation of thyroid mass and can be the first test to diagnose PTL as it is less invasive. But, FNA accurately diagnosed PTL in only 60% of patients due to histopathological similarities between PLT and HT [11]. Thus, confirmatory procedures such as incisional biopsy are highly recommended to obtain sufficient material.

The therapeutic options of PTL

Appropriate treatment for PTL depends on histologic subtype or extent of disease. The therapeutic approach for patients with PTL has been revised over the last a few decades. Conservative treatment mainly with combination chemotherapy has replaced thyroidectomy as mainstay of therapy because effective chemotherapeutic regimens have been introduced. Nowadays, surgery is usually utilized to obtain sufficient tissue for diagnosis, not for radical therapy. For DLBCL of the thyroid, basically, treatment should be the same as DLBCL of any other site or extent. In limited DLBCL, three cycles of CHOP plus IFRT had been considered as standard treatment [18]. Recently, R-CHOP chemotherapy is the gold standard for this type of lymphoma. The addition of rituximab, a monoclonal antibody against the membrane antigen CD-20 found on pre-B and matured B lymphocytes, led to significant improvement in event-free and overall survival (OS) when compared with CHOP alone [19]. Even in patients with severe airway compromise, the tumor can be expected to shrink, which provides symptomatic relief, briefly after initiation of combination chemotherapy [20]. In limited DLBCL, there are no large randomized trials of R-CHOP plus radiation therapy, while, in phase II study of limited DLBCL, three cycles of R-CHOP plus IFRT led to better outcome of progression-free survival (PFS) and OS at 2 and 4 years when compared with three cycles of CHOP plus IFRT [21].

Our comments of the present case

The prognosis of patients with DLBCL has been estimated using the International Prognostic Index (IPI) (age > 60, stage III/IV disease, elevated LDH level, Eastern Cooperative Oncology Group performance status ≥ 2, more than one extranodal site of disease) [22]. As the present case had an IPI score of 2, he was assigned into ‘low-intermediate’ group, indicating his 4-year OS of 81% with R-CHOP therapy [23]. According to revised IPI (R-IPI) which is on the basis of the same parameters but grouped differently as conventional IPI, the present case was assigned into ‘good’ group, indicating his 4-year OS of 79% with R-CHOP therapy [23].

Recently, immunohistochemical expression of CD10, bcl-6, or MUM1 could classify DLBCL into prognostically significant subgroup with germinal center B-cell(GCB) and non-GCB, and 5-year OS with an anthracycline-containing chemotherapy regimen are 92% in GCB, and 44% in non-GCB, respectively [24]. In this patient, CD10 and bcl-6, both are GCB markers, were positive results predictive of better OS.

Through our experience obtained from the present case, it should be emphasized that PTL is entirely different from follicular epithelial-derived thyroid malignancy in disease management, and if PTL is clinically suspected, an incisional biopsy of the thyroid grand is highly recommended because combined pathology and immunohistochemistry can aid in confirmation of histopathology or histologic subtypes, making therapeutic planning, and predicting prognosis of the patients.

Conclusion

In patients with rapidly growing thyroid causing progressive compression symptoms, PTL with B-cell origin should be highly suspected. HT is a significant predisposing factor for PTL. An incisional biopsy of the thyroid grand is highly recommended for combined pathology and immunohistochemistry, which can aid in confirmation of histopathology or histologic subtypes, making therapeutic planning, and predicting prognosis of the patients. In DLBCL of the thyroid, basically, treatment is the same manner as DLBCL of any other site or extent. R-CHOP chemotherapy is a therapeutic mainstay and can dramatically shrink the tumor and briefly resolve the compression symptoms.

Grant Support

None.


References▴Top
  1. Nix P, Nicolaides A, Coatesworth AP. Thyroid cancer review 2: management of differentiated thyroid cancers. Int J Clin Pract. 2005;59(12):1459-1463.
    pubmed doi
  2. Nix PA, Nicolaides A, Coatesworth AP. Thyroid cancer review 3: management of medullary and undifferentiated thyroid cancer. Int J Clin Pract. 2006;60(1):80-84.
    pubmed doi
  3. Anderson T, Chabner BA, Young RC, Berard CW, Garvin AJ, Simon RM, DeVita VT, Jr. Malignant lymphoma. 1. The histology and staging of 473 patients at the National Cancer Institute. Cancer. 1982;50(12):2699-2707.
    pubmed doi
  4. Thieblemont C, Mayer A, Dumontet C, Barbier Y, Callet-Bauchu E, Felman P, Berger F, et al. Primary thyroid lymphoma is a heterogeneous disease. J Clin Endocrinol Metab. 2002;87(1):105-111.
    pubmed doi
  5. Carbone PP, Kaplan HS, Musshoff K, Smithers DW, Tubiana M. Report of the Committee on Hodgkin's Disease Staging Classification. Cancer Res. 1971;31(11):1860-1861.
    pubmed
  6. Zufferey P, Meyer OC, Grossin M, Kahn MF. Primary Sjogren's syndrome (SS) and malignant lymphoma. A retrospective cohort study of 55 patients with SS. Scand J Rheumatol. 1995;24(6):342-345.
    pubmed doi
  7. Lazarus MN, Robinson D, Mak V, Moller H, Isenberg DA. Incidence of cancer in a cohort of patients with primary Sjogren's syndrome. Rheumatology (Oxford). 2006;45(8):1012-1015.
    pubmed doi
  8. Carsons S. The association of malignancy with rheumatic and connective tissue diseases. Semin Oncol. 1997;24(3):360-372.
    pubmed
  9. Aozasa K. Pyothorax-associated lymphoma. J Clin Exp Hematop. 2006;46(1):5-10.
    pubmed doi
  10. Hussell T, Isaacson PG, Crabtree JE, Spencer J. The response of cells from low-grade B-cell gastric lymphomas of mucosa-associated lymphoid tissue to Helicobacter pylori. Lancet. 1993;342(8871):571-574.
    pubmed doi
  11. Hwang YC, Kim TY, Kim WB, Shong YK, Yi KH, Shong M, Jo YS, et al. Clinical characteristics of primary thyroid lymphoma in Koreans. Endocr J. 2009;56(3):399-405.
    pubmed doi
  12. Holm LE, Blomgren H, Lowhagen T. Cancer risks in patients with chronic lymphocytic thyroiditis. N Engl J Med. 1985;312(10):601-604.
    pubmed doi
  13. Pedersen RK, Pedersen NT. Primary non-Hodgkin's lymphoma of the thyroid gland: a population based study. Histopathology. 1996;28(1):25-32.
    pubmed doi
  14. Graff-Baker A, Sosa JA, Roman SA. Primary thyroid lymphoma: a review of recent developments in diagnosis and histology-driven treatment. Curr Opin Oncol. 2010;22(1):17-22.
    pubmed doi
  15. Moshynska OV, Saxena A. Clonal relationship between Hashimoto thyroiditis and thyroid lymphoma. J Clin Pathol. 2008;61(4):438-444.
    pubmed doi
  16. Takakuwa T, Miyauchi A, Aozasa K. Aberrant somatic hypermutations in thyroid lymphomas. Leuk Res. 2009;33(5):649-654.
    pubmed doi
  17. Matsuzuka F, Miyauchi A, Katayama S, Narabayashi I, Ikeda H, Kuma K, Sugawara M. Clinical aspects of primary thyroid lymphoma: diagnosis and treatment based on our experience of 119 cases. Thyroid. 1993;3(2):93-99.
    pubmed doi
  18. Miller TP, Dahlberg S, Cassady JR, Adelstein DJ, Spier CM, Grogan TM, LeBlanc M, et al. Chemotherapy alone compared with chemotherapy plus radiotherapy for localized intermediate- and high-grade non-Hodgkin's lymphoma. N Engl J Med. 1998;339(1):21-26.
    pubmed doi
  19. Coiffier B, Lepage E, Briere J, Herbrecht R, Tilly H, Bouabdallah R, Morel P, et al. CHOP chemotherapy plus rituximab compared with CHOP alone in elderly patients with diffuse large-B-cell lymphoma. N Engl J Med. 2002;346(4):235-242.
    pubmed doi
  20. Sarinah B, Hisham AN. Primary lymphoma of the thyroid: diagnostic and therapeutic considerations. Asian J Surg. 2010;33(1):20-24.
    pubmed doi
  21. Persky DO, Unger JM, Spier CM, Stea B, LeBlanc M, McCarty MJ, Rimsza LM, et al. Phase II study of rituximab plus three cycles of CHOP and involved-field radiotherapy for patients with limited-stage aggressive B-cell lymphoma: Southwest Oncology Group study 0014. J Clin Oncol. 2008;26(14):2258-2263.
    pubmed doi
  22. A predictive model for aggressive non-Hodgkin's lymphoma. The International Non-Hodgkin's Lymphoma Prognostic Factors Project. N Engl J Med. 1993;329(14):987-994.
    pubmed doi
  23. Sehn LH, Berry B, Chhanabhai M, Fitzgerald C, Gill K, Hoskins P, Klasa R, et al. The revised International Prognostic Index (R-IPI) is a better predictor of outcome than the standard IPI for patients with diffuse large B-cell lymphoma treated with R-CHOP. Blood. 2007;109(5):1857-1861.
    pubmed doi
  24. Alacacioglu I, Ozcan MA, Ozkal S, Piskin O, Turgut N, Demirkan F, Ozsan GH, et al. Prognostic significance of immunohistochemical classification of diffuse large B-cell lymphoma. Hematology. 2009;14(2):84-89.
    pubmed doi
